Optimum OPTIsaw S 100G Portable Bandsaw
Optimum OPTIsaw S 100G Portable Bandsaw
Regular price
£1,074.00 GBP
Regular price
Sale price
£1,074.00 GBP
Unit price
/
per
Couldn't load pickup availability
Share
Light and handy
- Quick-action vice for fast workpiece clamping
- Saw bar can be swiveled from 0 ° to 45 ° to allow angled saw cuts
- Easy to read scale for angle adjustment
- Micro switch for automatic limit switch
- Automatic lowering of the saw bar via three-stage adjustable saw bar lowering pressure
- As standard with high-quality bi-metal saw band
- Large, handy handle and low weight allows easy transport to the construction site
- Adjustable material stop for serial work
- Fully equipped machine; The user can work productively immediately after commissioning
- transport safety
DELIVERY CONTENTS
- Material stop
- Operating tool
- Bi-Metal band saw blade
TECHNICAL SPEC
| Dimensions and Weights | |||
| Length (product) approx. | 850mm | Width/depth (product) approx. | 300mm |
| Height (product) approx. | 680mm | Net weight approx. | 23kg |
| Length max. (product) approx. | 950mm | Max. width/depth (product) approx. | 660mm |
| Height max. (product) approx. | 820mm | ||
| Electrical Data | |||
| Drive motor output |
0.37kW | Supply voltage |
230V |
| Mains frequency | 50Hz | ||
| Machine Data | |||
| Saw band speed(s) | 45 m/min | Saw band length | 1470mm |
| Saw band width | 13mm | Saw band thickness | 0.65mm |
| Cutting angle | 0 – 45° | ||
| Cutting Ranges | |||
| Cutting range 0° round (solid material) | 100mm | Cutting range 0° square (solid material) | 100mm |
| Cutting range 0° rectangular lying (solid material) | 100 x 150mm | Clamping range +45° round (full material) | 65mm |
| Cutting range +45° square (solid material) | 60mm | Cutting range +45° rectangular horizontal (solid material) | 60 x 100mm |
